Emtron DX-2SP/>
| Type: |
Power Amplifier |
| Frequency Range: |
10-160 m + WARC |
| Voltage: |
Mains: 100-240 VAC |
| Current Drain: |
10 A @ 240 VAC |
| Drive power: |
30-60 W |
| Maximum output power: |
SSB: 2.5 KW (PEP)
CW: 2 KW |
| Dimensions (W*H*D): |
470 x 230 x 470 mm (18.5 x 9 x 18.5 inches) |
| Weight: |
35 Kg (100 lbs) |
| Manufactured: |
Australia: 20xx-201x |
| Other: |
Full QSK.
Power device: 1*FU-728F tube.
Modular design with interchangeability between models |
| Related Documents: |
|
 |
